NVIDIA RTX 5070 - Priser, Spesifikasjoner og informasjon

NVIDIA RTX 5070

NVIDIA RTX 5070

RTX 5070 er et consumer-klasse grafikkort fra NVIDIAs GeForce RTX 50-serie, bygget på Blackwell 2nd-gen-arkitekturen med GB205-brikken. Utstyrt med 12 GB GDDR7-minne på en 192-bit buss, og leverer 672.0 GB/s båndbredde ved 28.0 Gbps.
Laveste priser
6 790,-
MSI GeForce RTX 5070 VENTUS 2X OC

Historiske priser

Spesifikasjoner

Informasjon
PlattformConsumer
ArkitekturBlackwell 2nd-gen
GenerasjonGeForce RTX 50
Forrige generasjonGeForce RTX 40
NavnGB205
GrensesnittPCIe 5.0 x16
Kjerne
NavnGB205
FabrikantTSMC
Prosessnode5 nm
Transistorer31100 million
Brikkestørrelse263.0 mm²
Tetthet118.3 /mm²
GPU-kjernekonfigurasjon
Kjerner6144
TMU192
ROP80
SM-er48
Tensor-kjerner192
Minne
TeknologiGDDR7
Størrelse12 GB
Buss192 bit
Båndbredde672.0 GB/s
Hastighet28.0 Gbps

Klokkehastigheter
Grunnklokke2325 MHz
Boost-klokke2512 MHz
Minneklokke1750 MHz
Strøm
16-pin1
TDP250 w
Anbefalt strømforsyning650 w
Skjermutgang
DisplayPort3 2.1b
HDMI1 2.1b
HDCP2.3
Dimensjoner
Spor2
Lengde242 mm
Høyde112 mm
Bredde40 mm

Modeller

Skjermkort▲	Pris▲	Boost-klokke▲	Spor▲	Lengde▲	Høyde▲	Bredde▲
Asus ROG Strix GeForce RTX 5070 ROG-STRIX-RTX5070-12G-GAMING		2512 MHz	3.2	332 mm	147.3 mm	64 mm
Asus ROG Strix GeForce RTX 5070 OC Edition ROG-STRIX-RTX5070-O12G-GAMING	12 390,-	2655 MHz +5.7%	3.2	332 mm	147.3 mm	64 mm
Zotac GeForce RTX 5070 AMP White Edition ZT-B50700FQ-10P	9 676,-	2587 MHz +3.0%	2.1	304.4 mm	115.8 mm	41.6 mm
Zotac GeForce RTX 5070 SOLID OC ZT-B50700J-10P	9 561,-	2542 MHz +1.2%	2.1	304.4 mm	115.8 mm	41.6 mm
Zotac GeForce RTX 5070 SOLID ZT-B50700D-10P		2512 MHz	2.1	304.4 mm	115.8 mm	41.6 mm
Zotac GeForce RTX 5070 Twin Edge OC White Edition ZT-B50700Q-10P	9 561,-	2542 MHz +1.2%	2.1	241.5 mm	120.1 mm	40.6 mm
Zotac GeForce RTX 5070 Twin Edge OC ZT-B50700H-10P	9 429,-	2542 MHz +1.2%	2.1	241.5 mm	120.1 mm	40.6 mm
Zotac GeForce RTX 5070 Twin Edge ZT-B50700E-10P	10 282,-	2512 MHz	2.1	241.5 mm	120.1 mm	40.6 mm
Gigabyte AORUS GeForce RTX 5070 MASTER GV-N5070AORUS M-12GD	10 889,-	2715 MHz +8.1%	3.2	317 mm	136 mm	64 mm
Gigabyte GeForce RTX 5070 GAMING OC GV-N5070GAMING OC-12GD	9 999,- 10 032,-	2625 MHz +4.5%	2.8	327 mm	132 mm	56 mm
Gigabyte GeForce RTX 5070 GAMING GV-N5070GAMING-12GD		2512 MHz	2.8	327 mm	132 mm	56 mm
Gigabyte GeForce RTX 5070 EAGLE OC ICE SFF GV-N5070EAGLEOC ICE-12GD	9 802,-	2587 MHz +3.0%	2.5	290 mm	120 mm	50 mm
Gigabyte GeForce RTX 5070 EAGLE OC SFF GV-N5070EAGLE OC-12GD	8 790,- 10 751,-	2587 MHz +3.0%	2.5	290 mm	120 mm	50 mm
Gigabyte GeForce RTX 5070 AERO OC GV-N5070AERO OC-12GD	13 483,-	2625 MHz +4.5%	2.8	324 mm	130 mm	56 mm
Gigabyte GeForce RTX 5070 AERO GV-N5070AERO-12GD		2512 MHz	2.8	324 mm	130 mm	56 mm
Gigabyte GeForce RTX 5070 WINDFORCE OC SFF GV-N5070WF3OC-12GD	7 990,-	2542 MHz +1.2%	2.5	282 mm	110 mm	50 mm
Gigabyte GeForce RTX 5070 WINDFORCE SFF GV-N5070WF3-12GD	7 999,-	2512 MHz	2.5	282 mm	110 mm	50 mm
Asus Dual GeForce RTX 5070 EVO OC Edition DUAL-RTX5070-O12G-EVO		2542 MHz +1.2%	2.5	229 mm	120 mm	50 mm
Asus Dual GeForce RTX 5070 EVO DUAL-RTX5070-12G-EVO		2512 MHz	2.5	229 mm	120 mm	50 mm
Asus PRIME GeForce RTX 5070 White OC Edition PRIME-RTX5070-O12G-WHITE	9 790,-	2557 MHz +1.8%	2.5	304 mm	126 mm	50 mm
Asus Dual GeForce RTX 5070 DUAL-RTX5070-12G		2512 MHz	2.6	249 mm	126 mm	50.6 mm
Asus Dual GeForce RTX 5070 OC Edition DUAL-RTX5070-O12G	8 990,-	2542 MHz +1.2%	2.6	249 mm	126 mm	50.6 mm
Asus TUF Gaming GeForce RTX 5070 TUF-RTX5070-12G-GAMING		2512 MHz	3.2	329 mm	140 mm	62.5 mm
Asus TUF Gaming GeForce RTX 5070 OC Edition TUF-RTX5070-O12G-GAMING	11 690,-	2610 MHz +3.9%	3.2	329 mm	140 mm	62.5 mm
Asus PRIME GeForce RTX 5070 PRIME-RTX5070-12G		2512 MHz	2.5	304 mm	126 mm	50 mm
Asus PRIME GeForce RTX 5070 OC Edition PRIME-RTX5070-O12G	8 990,-	2557 MHz +1.8%	2.5	304 mm	126 mm	50 mm
MSI GeForce RTX 5070 World of Warcraft MIDNIGHT VOID EDITION OC G507012WMVEC		2610 MHz +3.9%	2.5	338 mm	140 mm	50 mm
MSI GeForce RTX 5070 World of Warcraft MIDNIGHT LIGHT EDITION OC G507012WMLEC		2610 MHz +3.9%	2.5	338 mm	140 mm	50 mm
MSI GeForce RTX 5070 GAMING DUKE 3X WHITE G5070-12D3W		2512 MHz	2.3	325 mm	121 mm	45 mm
MSI GeForce RTX 5070 GAMING DUKE 3X OC WHITE G5070-12D3CW		2557 MHz +1.8%	2.3	325 mm	121 mm	45 mm
MSI GeForce RTX 5070 GAMING DUKE 3X G5070-12D3		2512 MHz	2.3	325 mm	121 mm	45 mm
MSI GeForce RTX 5070 GAMING DUKE 3X OC G5070-12D3C		2557 MHz +1.8%	2.3	325 mm	121 mm	45 mm
MSI GeForce RTX 5070 SHADOW 3X G5070-12S3		2512 MHz	2.5	303 mm	121 mm	49 mm
MSI GeForce RTX 5070 SHADOW 3X OC G5070-12S3C		2542 MHz +1.2%	2.5	303 mm	121 mm	49 mm
MSI GeForce RTX 5070 SHADOW 2X G5070-12S2		2512 MHz	2.5	231 mm	126 mm	50 mm
MSI GeForce RTX 5070 SHADOW 2X OC G5070-12S2C		2542 MHz +1.2%	2.5	231 mm	126 mm	50 mm
MSI GeForce RTX 5070 VANGUARD SOC LAUNCH EDITION G5070-12VGSL		2640 MHz +5.1%	3.1	337 mm	140 mm	61 mm
MSI GeForce RTX 5070 VANGUARD SOC G5070-12VGS		2640 MHz +5.1%	3.1	337 mm	140 mm	61 mm
MSI GeForce RTX 5070 VANGUARD OC G5070-12VGC		2610 MHz +3.9%	3.1	337 mm	140 mm	61 mm
MSI GeForce RTX 5070 GAMING TRIO G5070-12GT		2512 MHz	2.5	338 mm	140 mm	50 mm
MSI GeForce RTX 5070 GAMING TRIO OC G5070-12GTC	8 847,-	2610 MHz +3.9%	2.5	338 mm	140 mm	50 mm
MSI GeForce RTX 5070 GAMING TRIO WHITE G5070-12GTW		2512 MHz	2.5	338 mm	140 mm	50 mm
MSI GeForce RTX 5070 GAMING TRIO OC WHITE G5070-12GTCW		2610 MHz +3.9%	2.5	338 mm	140 mm	50 mm
MSI GeForce RTX 5070 INSPIRE 3X G5070-12I3		2512 MHz	2.5	288 mm	112 mm	50 mm
MSI GeForce RTX 5070 INSPIRE 3X OC G5070-12I3C		2542 MHz +1.2%	2.5	288 mm	112 mm	50 mm
MSI GeForce RTX 5070 VENTUS 3X G5070-12V3		2512 MHz	2.5	302 mm	121 mm	49 mm
MSI GeForce RTX 5070 VENTUS 3X OC G5070-12V3C		2542 MHz +1.2%	2.5	302 mm	121 mm	49 mm
MSI GeForce RTX 5070 VENTUS 2X WHITE G5070-12V2W		2512 MHz	2.5	236 mm	126 mm	50 mm
MSI GeForce RTX 5070 VENTUS 2X OC WHITE G5070-12V2CW	8 190,-	2542 MHz +1.2%	2.5	236 mm	126 mm	50 mm
MSI GeForce RTX 5070 VENTUS 2X G5070-12V2		2512 MHz	2.5	236 mm	126 mm	50 mm
MSI GeForce RTX 5070 VENTUS 2X OC G5070-12V2C	6 790,-	2542 MHz +1.2%	2.5	236 mm	126 mm	50 mm
Palit GeForce RTX 5070 White OC NE75070U19K9-GB2050W	10 079,-	2527 MHz +0.6%	2.1	291.9 mm	116.6 mm	41.3 mm
Palit GeForce RTX 5070 Infinity 3 NE75070019K9-GB2050S	9 340,-	2512 MHz	2.1	291.9 mm	116.6 mm	41.3 mm
Palit GeForce RTX 5070 Infinity 3 OC NE75070S19K9-GB2050S	9 232,-	2542 MHz +1.2%	2.1	291.9 mm	116.6 mm	41.3 mm
Palit GeForce RTX 5070 GamingPro-S NE75070019K9-GB2050U		2512 MHz	2.5	331.9 mm	127.1 mm	49.7 mm
Palit GeForce RTX 5070 GamingPro-S OC NE75070T19K9-GB2050U		2572 MHz +2.4%	2.5	331.9 mm	127.1 mm	49.7 mm
Palit GeForce RTX 5070 GamingPro NE75070019K9-GB2050A		2512 MHz	3	331.9 mm	127.1 mm	60 mm
Palit GeForce RTX 5070 GamingPro OC NE75070T19K9-GB2050A		2572 MHz +2.4%	3	331.9 mm	127.1 mm	60 mm
PNY GeForce RTX 5070 Slim Dual Fan Overclocked VCG507012DFSXPB1-O	10 481,-	2587 MHz +3.0%	2	290 mm	128 mm	40 mm
PNY GeForce RTX 5070 Slim Dual Fan VCG507012DFSXPB1		2512 MHz	2	290 mm	128 mm	40 mm
PNY GeForce RTX 5070 ARGB EPIC-X RGB Overclocked Triple Fan VCG507012TFXXPB1-O	9 877,-	2640 MHz +5.1%	2.4	299.7 mm	120.1 mm	48.3 mm
PNY GeForce RTX 5070 ARGB EPIC-X RGB Triple Fan VCG507012TFXXPB1		2510 MHz -0.1%	2.4	299.7 mm	120.1 mm	48.3 mm
PNY GeForce RTX 5070 Triple Fan VCG507012TFXPB1	9 877,-	2510 MHz -0.1%	2.4	299.7 mm	120.1 mm	48.3 mm
PNY GeForce RTX 5070 Overclocked Triple Fan VCG507012TFXPB1-O		2685 MHz +6.9%	2.4	299.7 mm	120.1 mm	48.3 mm
Gainward GeForce RTX 5070 Phoenix-S NE75070019K9-GB2050K		2512 MHz	2.5	331.9 mm	127.1 mm	49.4 mm
Gainward GeForce RTX 5070 Phoenix-S GS NE75070T19K9-GB2050K		2572 MHz +2.4%	2.5	331.9 mm	127.1 mm	49.4 mm
Gainward GeForce RTX 5070 Phoenix NE75070019K9-GB2050X		2512 MHz	3	331.9 mm	133.1 mm	60 mm
Gainward GeForce RTX 5070 Phoenix GS NE75070T19K9-GB2050X	10 122,-	2572 MHz +2.4%	3	331.9 mm	133.1 mm	60 mm
NVIDIA GeForce RTX 5070 Founders Edition 900-1G146-2570-000		2512 MHz	2	242 mm	112 mm	40 mm
Gainward GeForce RTX 5070 Python III NE75070019K9-GB2050T	10 658,-	2512 MHz	2.1	291.9 mm	116.5 mm	41.3 mm
Inno3D GeForce RTX 5070 X3 OC N50703-12D7X-195064L	8 990,-	2542 MHz +1.2%	2.1	300 mm	116 mm	41 mm
Inno3D GeForce RTX 5070 TWIN X2 OC N50702-12D7X-195064N	8 890,- 9 462,-	2542 MHz +1.2%	2.1	250 mm	116 mm	41 mm
Inno3D GeForce RTX 5070 TWIN X2 N50702-12D7-195064N	8 790,-	2512 MHz	2.1	250 mm	116 mm	41 mm
Inno3D GeForce RTX 5070 TWIN X2 OC WHITE N50702-12D7X-195064W		2542 MHz +1.2%	2.1	250 mm	116 mm	41 mm
Inno3D GeForce RTX 5070 iCHILL X3 C50703-12D7X-195065H	10 589,-	2572 MHz +2.4%	3.1	334 mm	148 mm	61 mm
MSI GeForce RTX 5070 VENTUS 2X OC BLACK G5070-12V2CB		2557 MHz +1.8%	2.5	236 mm	126 mm	50 mm
Asus T1 GeForce RTX 5070 OC Edition T1-RTX5070-O12G-GAMING	10 427,-	2595 MHz +3.3%	2.5	305 mm	126 mm	50 mm
Gainward GeForce RTX 5070 Python III OC NE75070S19K9-GB2050T	10 352,-	2542 MHz +1.2%	2.1	291.9 mm	116.5 mm	41.3 mm
Gigabyte AORUS GeForce RTX 5070 INFINITY GV-N5070AORUS IF-12GD	10 290,-	2715 MHz +8.1%	2.8	309 mm	132 mm	55 mm

Plattform	Consumer
Arkitektur	Blackwell 2nd-gen
Generasjon	GeForce RTX 50
Forrige generasjon	GeForce RTX 40
Navn	GB205
Grensesnitt	PCIe 5.0 x16

Navn	GB205
Fabrikant	TSMC
Prosessnode	5 nm
Transistorer	31100 million
Brikkestørrelse	263.0 mm²
Tetthet	118.3 /mm²

Teknologi	GDDR7
Størrelse	12 GB
Buss	192 bit
Båndbredde	672.0 GB/s
Hastighet	28.0 Gbps

Kjerner	6144
TMU	192
ROP	80
SM-er	48
Tensor-kjerner	192

Grunnklokke	2325 MHz
Boost-klokke	2512 MHz
Minneklokke	1750 MHz

16-pin	1
TDP	250 w
Anbefalt strømforsyning	650 w

DisplayPort	3 2.1b
HDMI	1 2.1b
HDCP	2.3
